Rocker Switches 1118-56/56A/56B/56AM1/56BM1/56BM/56M

Rocker Switch
12VDC 16Amps; 24VDC 10Amps
125VAC 16Amps; 250VAC 10Amps.
Contact Resistance: 50m Ω Max.
Insulation Resistance: DC 500V 100m Ω Min.
Dielectric Strength: AC 1500V 1 minute.
Electrical Life: 20,000 cycles.
4 terminals or 6 terminals (screw type or plug-in type)

For Plug-in Type Terminals, Add "P" At The End.
Ex. AES-1118-56P.
