Illuminated Rocker Switch 1118-53, 53-L, 53M, 53P, 53P-L, 53PM, 53PS-R

型號 ID:1118-53, 53-L, 53M, 53P, 53P-L, 53PM, 53PS-R
Illuminated Rocker Switch
12VDC 16Amps; 24VDC 10Amps
125VAC 16Amps; 250VAC 10Amps.
Contact Resistance: 50mΩ Max.
Insulation Resistance: DC 500V 100mΩ Min.
Dielectric Strength: AC 1500V 1 minute.
Electrical Life: 20,000 cycles.
SPST, 3 terminals (screw type or plug-in type)

AES-1118-53PS-R With Soft Red Cover, SPST, 3P, ON-OFF, Plug-in Type Terminal.
